NEW

DHI-HY-1022

• 0
• 1
• 2
• 3
• 4
• 5

0 opinion

4,845,000 uzs

available in stock

Product Brief:

• Model: DHI-HY-1022

• Type: Addressable Fire Alarm Control Panel

• Working voltage: 16V–28V DC

• Main power: AC 90–240V / 50–60Hz

• Backup power: 2 × 12V/5Ah lead-acid batteries

• System capacity: Up to 254 field devices (recommended: 200)

• Loop number: 1

• Display: 4.3” LCD (480 × 272)

• Printer: Micro thermal printer

• Protection grade: IP30

• Operating temperature: −10°C to +40°C

• Humidity: ≤ 95% RH (non-condensing)

• Dimensions: 333 × 115 × 480 mm

• Weight: 7 kg (10 kg with batteries)

Data

• Model: DHI-HY-1022

• Type: Addressable Fire Alarm Control Panel

• Working voltage: 16V–28V DC

• Main power: AC 90–240V / 50–60Hz

• Backup power: 2 × 12V/5Ah lead-acid batteries

• System capacity: Up to 254 field devices (recommended: 200)

• Loop number: 1

• Display: 4.3” LCD (480 × 272)

• Printer: Micro thermal printer

• Protection grade: IP30

• Operating temperature: −10°C to +40°C

• Humidity: ≤ 95% RH (non-condensing)

• Dimensions: 333 × 115 × 480 mm

• Weight: 7 kg (10 kg with batteries)
